AC7960 Specifications

  • Updated
SpecificationDetails
MaterialAluminum Alloy, Gray
AirplaySupported
MiracastSupported
WIDISupported
Google CastNot supported
Multi-View2 sources
Max. Paired Presenter Buttons16 pieces
LAN100 Mbps (1x)
AntennaReceiving Sensitivity: -70 dBm
Transmission ProtocolIEEE 802.11ac/802.11n
Encryption ProtocolWPA2-PSK
Frequency Band2.4 GHz / 5 GHz (default)
Video Latency≈ 150 ms
Connection Range20 meters (unobstructed)
CodecH.264 + H.265
Supported Systems

• Windows 10 or later, 32 & 64 bit

• Mac OS 10.14 or later
• Android 9 or later
• iOS 11 or later



HDMI Output• 3840x2160P60
• 1920x1200P60
• 1920x1080P60
• 1280x720P60
• 1024x768P60
Audio Output3.5mm stereo jack (1x)
HDMI: 44.1 kHz/16-bit PCM 2.0
USB Type-CFor pairing presenter buttons.
USB-A2x USB-A female port for connecting mouse or touch device and multi-media playback.
LED
  1. Booting - Blue LED lights up for a few seconds.
  2. Waiting - Blue LED flashing; Power-On completed.
  3. Connected - Blue LED static ON; Connection established.
  4. Casting - Red LED static ON; Screen casting established.
Reset ButtonPress for 5 seconds to perform factory reset
Dimensions(WxDxH) 14.5cm x 10.8cm x 3.0cm
Storage Humidity0 to 90% relative humidity, non-condensing
Operating Humidity0 to 85% relative humidity, non-condensing
Weight342 grams
Power Supply12 Volt, 2A
